ION 171 Aftermarket Wheel
ION 171 Aftermarket Wheel
Couldn't load pickup availability
The ION 171 is an aftermarket wheel for trucks, Jeeps, and SUVs, available in 15-, 16-, 17-, and 18-inch diameters with widths of 8 or 10 inches. Sold individually (price is per wheel, not per set). Across 64 variants, bolt patterns span 5-127 through 8-170, offsets range from -38 mm to 0 mm, and three finishes are offered: Polished, Gloss Black Machined, and Matte Black.
Wide Fitment Range Across One Catalog
The ION 171 is offered in bolt patterns from 5-127 to 8-170, covering a broad range of 5-, 6-, and 8-lug applications. Hub bores across the lineup run from 83.82 mm to 130.8 mm, accommodating the hub diameters common to light trucks and full-size SUVs. When the bolt pattern and hub bore match a vehicle's hub exactly, no centering rings or adapters are needed: a direct swap rather than a workaround.
Size and Offset Options That Change Stance
Six diameter-and-width combinations are available: 15x8, 15x10, 16x8, 16x10, 17x9, and 18x9. These give buyers meaningful choices between a tighter stock-look stance and a wider, more aggressive fitment. Offsets range from -38 mm (deep negative, pushing the face outward) to 0 mm (flush), so the same wheel design can be tuned to sit differently under the fender depending on the variant chosen. Selecting the right offset for a given suspension setup and tire clearance is the buyer's responsibility; the SKU table below lists the exact offset for every variant.
Three Finish Options, One Consistent Design
The 171 design is available in Polished, Gloss Black Machined, and Matte Black. The Gloss Black Machined finish combines a dark base with machined highlights on the face. One 15x8 variant (SKU 171-5885MB) is offered in a Matte Black (Hub 108) finish on the 6-139.7 bolt pattern. That variant carries a 108 mm hub bore, while the standard 6-139.7 Matte Black variants carry a 106 mm bore, so confirm the hub bore column before selecting that variant.
Features
- Four diameter options: 15-, 16-, 17-, and 18-inch diameters available
- Two width options: 8- and 10-inch widths depending on size
- Broad bolt-pattern coverage: 5-127, 5-135, 5-139.7, 6-114.3, 6-135, 6-139.7, 8-165.1, and 8-170
- Negative to flush offsets: -38 mm, -27 mm, -12 mm, -5 mm, and 0 mm across the lineup
- Three finish options: Polished, Gloss Black Machined, and Matte Black
- Designed in the U.S.A.: manufactured in Thailand
Specifications
| SKU | Size | Bolt Pattern | Offset | Hub Bore | Finish | Product Weight |
|---|---|---|---|---|---|---|
| 171-5173P | 15x10 | 5-127 | -38 mm | 83.82 mm | Polished | 23 lb |
| 171-5183B | 15x10 | 6-139.7 | -38 mm | 106 mm | Gloss Black Machined | 23 lb |
| 171-5183P | 15x10 | 6-139.7 | -38 mm | 106 mm | Polished | 23 lb |
| 171-5185B | 15x10 | 5-139.7 | -38 mm | 108 mm | Gloss Black Machined | 23 lb |
| 171-5185P | 15x10 | 5-139.7 | -38 mm | 108 mm | Polished | 23 lb |
| 171-5186P | 15x10 | 6-114.3 | -38 mm | 83.82 mm | Polished | 23 lb |
| 171-5873P | 15x8 | 5-127 | -27 mm | 83.82 mm | Polished | 21 lb |
| 171-5883MB | 15x8 | 6-139.7 | -27 mm | 106 mm | Matte Black | 21 lb |
| 171-5883P | 15x8 | 6-139.7 | -27 mm | 106 mm | Polished | 21 lb |
| 171-5885B | 15x8 | 5-139.7 | -27 mm | 108 mm | Gloss Black Machined | 21 lb |
| 171-5885MB | 15x8 | 6-139.7 | -27 mm | 108 mm | Matte Black (Hub 108) | 20 lb |
| 171-5885P | 15x8 | 5-139.7 | -27 mm | 108 mm | Polished | 21 lb |
| 171-5886B | 15x8 | 6-114.3 | -27 mm | 83.82 mm | Gloss Black Machined | 21 lb |
| 171-5886P | 15x8 | 6-114.3 | -27 mm | 83.82 mm | Polished | 21 lb |
| 171-6135P | 16x10 | 5-135 | -38 mm | 87 mm | Polished | 25 lb |
| 171-6170P | 16x10 | 8-170 | -38 mm | 130.8 mm | Polished | 25 lb |
| 171-6181B | 16x10 | 8-165.1 | -38 mm | 130.8 mm | Gloss Black Machined | 25 lb |
| 171-6181P | 16x10 | 8-165.1 | -38 mm | 130.8 mm | Polished | 25 lb |
| 171-6183P | 16x10 | 6-139.7 | -38 mm | 106 mm | Polished | 25 lb |
| 171-6185P | 16x10 | 5-139.7 | -38 mm | 108 mm | Polished | 25 lb |
| 171-6835B | 16x8 | 5-135 | -5 mm | 87 mm | Gloss Black Machined | 25 lb |
| 171-6835P | 16x8 | 5-135 | -5 mm | 87 mm | Polished | 25 lb |
| 171-6870B | 16x8 | 8-170 | -5 mm | 130.8 mm | Gloss Black Machined | 25 lb |
| 171-6870MB | 16x8 | 8-170 | -5 mm | 130.8 mm | Matte Black | 25 lb |
| 171-6870P | 16x8 | 8-170 | -5 mm | 130.8 mm | Polished | 25 lb |
| 171-6873MB | 16x8 | 5-127 | -5 mm | 83.82 mm | Matte Black | 25 lb |
| 171-6873P | 16x8 | 5-127 | -5 mm | 83.82 mm | Polished | 25 lb |
| 171-6881B | 16x8 | 8-165.1 | -5 mm | 130.8 mm | Gloss Black Machined | 25 lb |
| 171-6881MB | 16x8 | 8-165.1 | -5 mm | 130.8 mm | Matte Black | 25 lb |
| 171-6881P | 16x8 | 8-165.1 | -5 mm | 130.8 mm | Polished | 25 lb |
| 171-6883B | 16x8 | 6-139.7 | -5 mm | 106 mm | Gloss Black Machined | 25 lb |
| 171-6883MB | 16x8 | 6-139.7 | -5 mm | 106 mm | Matte Black | 25 lb |
| 171-6883P | 16x8 | 6-139.7 | -5 mm | 106 mm | Polished | 25 lb |
| 171-6885B | 16x8 | 5-139.7 | -5 mm | 108 mm | Gloss Black Machined | 25 lb |
| 171-6885P | 16x8 | 5-139.7 | -5 mm | 108 mm | Polished | 25 lb |
| 171-6886P | 16x8 | 6-114.3 | -5 mm | 83.82 mm | Polished | 25 lb |
| 171-7935B | 17x9 | 5-135 | 0 mm | 87 mm | Gloss Black Machined | 27 lb |
| 171-7935P | 17x9 | 5-135 | 0 mm | 87 mm | Polished | 27 lb |
| 171-7936B | 17x9 | 6-135 | 0 mm | 87 mm | Gloss Black Machined | 27 lb |
| 171-7936P | 17x9 | 6-135 | 0 mm | 87 mm | Polished | 27 lb |
| 171-7970MB | 17x9 | 8-170 | 0 mm | 130.8 mm | Matte Black | 27 lb |
| 171-7970P | 17x9 | 8-170 | 0 mm | 130.8 mm | Polished | 27 lb |
| 171-7973MB | 17x9 | 5-127 | 0 mm | 83.82 mm | Matte Black | 27 lb |
| 171-7973MB12 | 17x9 | 5-127 | -12 mm | 83.82 mm | Matte Black | 27 lb |
| 171-7973P | 17x9 | 5-127 | 0 mm | 83.82 mm | Polished | 27 lb |
| 171-7981B | 17x9 | 8-165.1 | 0 mm | 130.8 mm | Gloss Black Machined | 27 lb |
| 171-7981MB | 17x9 | 8-165.1 | 0 mm | 130.8 mm | Matte Black | 27 lb |
| 171-7981P | 17x9 | 8-165.1 | 0 mm | 130.8 mm | Polished | 27 lb |
| 171-7983B | 17x9 | 6-139.7 | 0 mm | 106 mm | Gloss Black Machined | 27 lb |
| 171-7983MB | 17x9 | 6-139.7 | 0 mm | 106 mm | Matte Black | 27 lb |
| 171-7983P | 17x9 | 6-139.7 | 0 mm | 106 mm | Polished | 27 lb |
| 171-7985B | 17x9 | 5-139.7 | 0 mm | 108 mm | Gloss Black Machined | 27 lb |
| 171-7985MB | 17x9 | 5-139.7 | 0 mm | 108 mm | Matte Black | 27 lb |
| 171-7985P | 17x9 | 5-139.7 | 0 mm | 108 mm | Polished | 27 lb |
| 171-8970B | 18x9 | 8-170 | 0 mm | 130.8 mm | Gloss Black Machined | 35 lb |
| 171-8970MB | 18x9 | 8-170 | 0 mm | 130.8 mm | Matte Black | 35 lb |
| 171-8970P | 18x9 | 8-170 | 0 mm | 130.8 mm | Polished | 35 lb |
| 171-8973MB | 18x9 | 5-127 | 0 mm | 83.82 mm | Matte Black | 35 lb |
| 171-8973P | 18x9 | 5-127 | 0 mm | 83.82 mm | Polished | 35 lb |
| 171-8981B | 18x9 | 8-165.1 | 0 mm | 130.8 mm | Gloss Black Machined | 35 lb |
| 171-8981MB | 18x9 | 8-165.1 | 0 mm | 130.8 mm | Matte Black | 35 lb |
| 171-8981P | 18x9 | 8-165.1 | 0 mm | 130.8 mm | Polished | 35 lb |
| 171-8983B | 18x9 | 6-139.7 | 0 mm | 106 mm | Gloss Black Machined | 35 lb |
| 171-8983P | 18x9 | 6-139.7 | 0 mm | 106 mm | Polished | 35 lb |
Who This Is For and Isn't
The ION 171 suits buyers replacing or upgrading wheels on trucks, Jeeps, or SUVs whose bolt pattern matches one of the eight listed (5-127, 5-135, 5-139.7, 6-114.3, 6-135, 6-139.7, 8-165.1, or 8-170) and whose hub bore matches the specific variant selected. The range of negative offsets makes the 171 a reasonable choice for buyers seeking a wider stance with larger-diameter tires.
The ION 171 does not fit any hub or bolt pattern outside those listed in the SKU table above. Lug nuts are not included. No load rating is published for this wheel; buyers with specific load-rating requirements should verify independently before purchasing.
Common Questions
Is the price for one wheel or a set of four?
The ION 171 is sold individually. The listed price is for one wheel. Buyers who need a full set of four should add four units to their cart and confirm that all four share the same SKU (size, bolt pattern, and finish) before ordering.
How do I confirm this wheel fits my vehicle?
Fitment depends on three numbers: bolt pattern, hub bore, and offset. Match your vehicle's bolt pattern and hub bore to the values in the SKU table above, then confirm the offset of the chosen variant works with your suspension geometry and tire clearance. No vehicle makes, models, or years are listed for the ION 171; use your vehicle's own spec sheet or a fitment guide to cross-reference.
What hub bore sizes are available?
The ION 171 is available with hub bores of 83.82 mm, 87 mm, 106 mm, 108 mm, and 130.8 mm depending on the variant. The hub bore is listed for every SKU in the specifications table. SKU 171-5885MB carries a 108 mm hub bore on the 6-139.7 bolt pattern; the other 6-139.7 variants in that size carry a 106 mm bore, so confirm the hub bore column before selecting that variant.
What finishes are available, and do they differ in any other way?
Three finishes are offered across the ION 171 lineup: Polished, Gloss Black Machined (dark base with machined face highlights), and Matte Black. Finish is a visual choice only; it does not change the size, offset, or hub bore of a given variant. Select the finish alongside the correct size and bolt pattern when choosing a SKU.
Where is the ION 171 manufactured?
The ION 171 wheel is manufactured in Thailand. ION notes that the design originates in the U.S.A., but the wheel itself is produced in Thailand across all 64 variants in this lineup.
Are lug nuts included?
Lug nuts are not included with the ION 171 wheel. Buyers should source lug nuts separately and confirm the correct thread pitch and seat type for their vehicle and the chosen wheel before installation.
