ION 167 Dually Wheel
ION 167 Dually Wheel
Couldn't load pickup availability
The ION 167 is a dually-specific aftermarket wheel available in three diameters (16-inch, 17-inch, and 20-inch), four bolt patterns (8-165.1, 8-170, 8-200, and 8-210), and three finishes (Gloss Black, Matte Black, and Polished). Price is per wheel. Front and rear positions use different offsets, so confirm the correct offset and hub bore for your axle position before ordering.
Dually-Specific Sizing Across Three Diameters
The ION 167 is offered in 16x6, 17x6.5, and 20x8.25 sizes, all proportioned for dual-rear-wheel applications where front and rear wheels carry different offsets. Front-position wheels use positive offsets (102 mm on 16-inch, 125.3 mm on 17-inch, 115 mm on 20-inch); rear-position wheels use negative offsets (-125 mm on 16-inch, -142 mm on 17-inch, -192 mm on 20-inch). Matching the correct offset to the correct axle position keeps the wheel centered in the wheel well and maintains proper load distribution on a dually setup.
Four Bolt Patterns, Multiple Hub Bores
The ION 167 spans four bolt patterns (8-165.1, 8-170, 8-200, and 8-210), with hub bores of 121.3 mm, 130.18 mm, 142 mm, 142.2 mm, or 154.2 mm depending on the specific SKU. Because hub bore varies even within the same bolt pattern, verify the hub bore of your vehicle's hub before selecting a variant. The SKU table on this page lists the hub bore for every combination.
Three Finishes, Consistent Construction
Gloss Black and Polished finishes are available across all three diameters; Matte Black is available on 17x6.5 variants only. ION designed the 167 for consistent performance and aesthetic durability across its finish options, making it a practical choice for buyers who want a clean, lasting look on a working dually without trading away structural integrity for style.
Features
- Dually application: front and rear offset variants available for all sizes and bolt patterns
- Three diameters: 16x6, 17x6.5, and 20x8.25
- Four bolt patterns: 8-165.1, 8-170, 8-200, and 8-210
- Three finishes: Gloss Black, Matte Black (17-inch only), and Polished
- Designed in the U.S.A.
Specifications
| SKU | Size | Bolt Pattern | Offset | Hub Bore | Finish | Position | Product Weight | Country |
|---|---|---|---|---|---|---|---|---|
| 167-2877GBF115 | 20x8.25 | 8-200 | +115 mm | 142 mm | Gloss Black | Front | 37 lb | China |
| 167-2877GBR192 | 20x8.25 | 8-200 | -192 mm | 142 mm | Gloss Black | Rear | 41 lb | China |
| 167-2877PF115 | 20x8.25 | 8-200 | +115 mm | 142 mm | Polished | Front | 37 lb | China |
| 167-2877PR192 | 20x8.25 | 8-200 | -192 mm | 142 mm | Polished | Rear | 41 lb | China |
| 167-2879GBF115 | 20x8.25 | 8-210 | +115 mm | 154.2 mm | Gloss Black | Front | 37 lb | Thailand |
| 167-2879GBR192 | 20x8.25 | 8-210 | -192 mm | 154.2 mm | Gloss Black | Rear | 40 lb | Thailand |
| 167-2879PF115 | 20x8.25 | 8-210 | +115 mm | 154.2 mm | Polished | Front | 37 lb | Thailand |
| 167-2879PR192 | 20x8.25 | 8-210 | -192 mm | 154.2 mm | Polished | Rear | 40 lb | Thailand |
| 167-2881GBF115 | 20x8.25 | 8-165.1 | +115 mm | 121.3 mm | Gloss Black | Front | 37 lb | China |
| 167-2881GBR192 | 20x8.25 | 8-165.1 | -192 mm | 121.3 mm | Gloss Black | Rear | 41 lb | China |
| 167-2881PF115 | 20x8.25 | 8-165.1 | +115 mm | 121.3 mm | Polished | Front | 37 lb | China |
| 167-2881PR192 | 20x8.25 | 8-165.1 | -192 mm | 121.3 mm | Polished | Rear | 41 lb | China |
| 167-6670FP | 16x6 | 8-170 | +102 mm | 130.18 mm | Polished | Front | 31 lb | Thailand |
| 167-6670RP | 16x6 | 8-170 | -125 mm | 130.18 mm | Polished | Rear | 31 lb | Thailand |
| 167-6681FP | 16x6 | 8-165.1 | +102 mm | 130.18 mm | Polished | Front | 31 lb | Thailand |
| 167-6681RP | 16x6 | 8-165.1 | -125 mm | 130.18 mm | Polished | Rear | 31 lb | Thailand |
| 167-7677FMB | 17x6.5 | 8-200 | +125.3 mm | 142 mm | Matte Black | Front | 32 lb | China |
| 167-7677FP | 17x6.5 | 8-200 | +125.3 mm | 142.2 mm | Polished | Front | 33 lb | Thailand |
| 167-7677RMB | 17x6.5 | 8-200 | -142 mm | 142 mm | Matte Black | Rear | 30 lb | China |
| 167-7677RP | 17x6.5 | 8-200 | -142 mm | 142.2 mm | Polished | Rear | 33 lb | Thailand |
| 167-7679FMB | 17x6.5 | 8-210 | +125.3 mm | 154.2 mm | Matte Black | Front | 32 lb | China |
| 167-7679FP | 17x6.5 | 8-210 | +125.3 mm | 154.2 mm | Polished | Front | 33 lb | Thailand |
| 167-7679RMB | 17x6.5 | 8-210 | -142 mm | 154.2 mm | Matte Black | Rear | 30 lb | China |
| 167-7679RP | 17x6.5 | 8-210 | -142 mm | 154.2 mm | Polished | Rear | 33 lb | Thailand |
| 167-7681FMB | 17x6.5 | 8-165.1 | +125.3 mm | 130.18 mm | Matte Black | Front | 32 lb | China |
| 167-7681FP | 17x6.5 | 8-165.1 | +125.3 mm | 130.18 mm | Polished | Front | 33 lb | Thailand |
| 167-7681RMB | 17x6.5 | 8-165.1 | -142 mm | 130.18 mm | Matte Black | Rear | 30 lb | China |
| 167-7681RP | 17x6.5 | 8-165.1 | -142 mm | 130.18 mm | Polished | Rear | 33 lb | Thailand |
Who This Is For and Isn't
The ION 167 suits buyers replacing or upgrading wheels on a dual-rear-wheel vehicle whose hub matches one of the four available bolt patterns (8-165.1, 8-170, 8-200, or 8-210) and the corresponding hub bore for their chosen SKU. Separate front and rear offset variants are available for every size and bolt pattern combination.
The ION 167 is not a single-rear-wheel or universal fitment wheel. Matte Black finish is not available in 16-inch or 20-inch sizes. No load rating is published for this wheel; buyers with specific load-rating requirements should confirm that information with ION before ordering. The 8-170 bolt pattern is available in 16-inch only.
Common Questions
Is the price for one wheel or a set of four?
The ION 167 is sold individually; the price shown is for one wheel. Buyers replacing all positions on a dually will need to select and order front and rear variants separately, as the two positions use different offsets.
Which offset should I choose: front or rear?
Front-position ION 167 wheels use positive offsets (102 mm on 16-inch, 125.3 mm on 17-inch, 115 mm on 20-inch). Rear-position wheels use negative offsets (-125 mm on 16-inch, -142 mm on 17-inch, -192 mm on 20-inch). Match the offset to the axle position you are replacing; mixing front and rear offsets on the same axle will affect wheel clearance and load geometry.
Does hub bore vary between SKUs with the same bolt pattern?
Yes. On the ION 167, hub bore depends on both bolt pattern and finish in some cases. For example, 17x6.5 wheels in 8-200 with Matte Black finish carry a 142 mm hub bore, while the same size and bolt pattern in Polished carry a 142.2 mm hub bore. Always verify the hub bore listed for your specific SKU against your vehicle's hub measurement before ordering.
Is Matte Black available in all sizes?
Matte Black finish on the ION 167 is available in the 17x6.5 size only. The 16x6 and 20x8.25 sizes are offered in Polished finish; the 20x8.25 size is also available in Gloss Black. Check the variant selector to confirm finish availability for your chosen size.
Where is the ION 167 manufactured?
Country of manufacture varies by SKU. Some ION 167 variants are made in China and others in Thailand, depending on the specific size, bolt pattern, and finish combination. The Specifications table on this page lists the country of manufacture for each individual SKU.
