ICON V.S. 2.5 Series Front Coilovers for 2021-2026 Ford F-150 4WD

The ICON V.S. 2.5 Series Front Coilovers (SKU 91724) are a bolt-on pair of internal-reservoir coilover shocks designed for 2021–2026 Ford F-150 4WD trucks, delivering 2.75–3.5 inches of lift height adjustability and a larger 2.5-inch shock body for improved damping over stock components. Note that PowerBoost hybrid models achieve a lift range of 2.5–3.25 inches and Power-Stroke diesel models achieve 2.25–3 inches over stock.

Shipping: ICON parts ship direct from ICON Vehicle Dynamics, mostly by UPS Ground. Lead times vary by part and some items are built to order, so please allow extra time. We email tracking as soon as your order ships.

More Damping Capacity Where It Counts

The 2.5-inch shock body provides greater piston area than stock front shocks, which translates directly to more consistent damping force across a wider range of terrain and speed. Whether the road surface is smooth pavement or a corrugated trail, the larger piston resists fade and maintains control in conditions that overwhelm smaller-diameter units. The internal nitrogen reservoir supports that consistency, keeping the shock fluid aerated and performing predictably under sustained hard use with no fade-out mid-run.

Vehicle-Specific Valving for Street and Trail

ICON tunes the valving for the F-150's specific weight, geometry, and suspension travel rather than applying a generic calibration. The result is a sport-tuned feel that works on paved roads without the harshness that often accompanies a lifted truck, and enough off-road compliance to handle uneven terrain confidently. FK rod end bearings at the lower mount reduce deflection and extend service life compared to rubber bushings, keeping the suspension geometry consistent over time.

Lift Range That Opens Up Wheel and Tire Options

The 2.75–3.5-inch adjustable lift range (on standard-engine models) creates clearance for larger wheel and tire combinations. Aftermarket wheels with lower offset and less backspace than typical OE fitments are recommended: 17x8.5-inch at 5-inch backspace/6mm offset, 18x9-inch at 5.25-inch backspace/6mm offset, or 20x9-inch at 5.625-inch backspace/16mm offset. Tire size up to 34x12.50 inches is recommended; larger tires may require fender trimming or other modifications.

Features

• 2.5-inch shock body: larger piston area than stock for improved damping capacity
• Internal nitrogen reservoir: maintains consistent performance under sustained hard use
• Adjustable lift height: 2.75–3.5 inches over stock (standard engine); varies by powertrain
• FK rod end bearings: extended longevity and minimal deflection at the lower mount
• 6061 aircraft-grade aluminum components: CNC machined; corrosion-resistant CAD-plated shock body with 7/8-inch shaft
• 100% bolt-on installation: no drilling, cutting, or welding required

Specifications

Who This Is For and Isn't

These coilovers suit 2021–2026 Ford F-150 4WD owners who want a meaningful lift with improved front damping for mixed on-road and off-road driving, and who are prepared to install ICON Delta Joint Pro upper control arms and have their Advanced Driver Assistance Systems recalibrated after installation.

These coilovers do not fit F-150 Tremor or F-150 Raptor models, any F-150 equipped with factory electronically controlled suspension, or 2WD F-150 variants. They are not compatible with all OE wheel and tire combinations; aftermarket wheels with lower offset and less backspace are recommended.

Common Questions

Do these coilovers work with the factory upper control arms?

The ICON V.S. 2.5 Series Front Coilovers for the 2021–2026 Ford F-150 4WD require ICON Delta Joint Pro upper control arms. The factory upper control arms are not compatible with this coilover system. Upper control arms are sold separately.

Will these fit my F-150 Raptor or Tremor?

No. The ICON V.S. 2.5 Series Front Coilovers (SKU 91724) do not fit the F-150 Raptor or F-150 Tremor. They are also incompatible with any F-150 equipped with factory electronically controlled suspension.

How much lift do PowerBoost hybrid or Power-Stroke diesel models get?

On a stock-equipped F-150 with the PowerBoost hybrid engine, these coilovers provide 2.5–3.25 inches of lift. On Power-Stroke diesel models, the lift range is 2.25–3 inches. Standard-engine F-150 4WD models achieve the full 2.75–3.5-inch range.

Is ADAS recalibration required after installation?

Yes. Installing the ICON V.S. 2.5 Series Front Coilovers on a 2021–2026 Ford F-150 requires recalibration of the vehicle's Advanced Driver Assistance Systems (ADAS) after installation. This is a required step, not optional.

What wheel and tire sizes are recommended after installing this lift?

Aftermarket wheels with lower offset and less backspace than typical OE fitments are recommended: 17x8.5-inch at 5-inch backspace/6mm offset, 18x9-inch at 5.25-inch backspace/6mm offset, or 20x9-inch at 5.625-inch backspace/16mm offset. Tires up to 34x12.50 inches are recommended; larger sizes may require fender trimming or modifications.
