ICON Stage 2 Suspension System for 2011-Up Ford Ranger T6 4WD 1-3" Lift

The ICON Vehicle Dynamics Stage 2 Suspension System for the 2011-and-newer Ford Ranger T6 4WD delivers a 1–3" adjustable lift using vehicle-specific-tuned 2.5" remote reservoir coilovers up front and 2.0 Aluminum Series remote reservoir monotube shocks in the rear, with no drilling, cutting, or welding required for installation.

Shipping: ICON parts ship direct from ICON Vehicle Dynamics, mostly by UPS Ground. Lead times vary by part and some items are built to order, so please allow extra time. We email tracking as soon as your order ships.

Front-to-Rear Balance on Any Terrain

The front 2.5" coilovers run ICON-engineered Eibach coil springs and a CAD-plated shock body with 7/8" shaft FK rod end bearings. That combination keeps deflection minimal and extends service life on the rough, varied surfaces the Ranger T6 regularly faces on a daily commute or a technical off-road trail. The 2.0 Aluminum Series monotube rear shocks match the front's capability so the truck doesn't feel mismatched end to end, giving a consistent, controlled ride across terrain types.

Remote Reservoirs Keep Damping Consistent

Both the front coilovers and the rear shocks carry remote reservoirs. Heat buildup during extended off-road use degrades damping consistency, and the additional fluid volume in the remote reservoirs keeps operating temperatures lower for longer, so damping stays consistent through the kind of sustained use the Ranger T6 is built for.

Adjustable Lift and Larger Tire Clearance

The 2.5" coilovers are height-adjustable across the full 1–3" lift range, so the Ranger T6 can be leveled front to back or set at a specific ride height without buying a different kit. At the recommended aftermarket fitment of 17×8.5 wheels with 5" backspace and 32×11.00" tires, no fender trimming is required. Larger tires may fit but will require fender trimming and modifications.

Features

• 2.5" Remote Reservoir Coilovers (Front): vehicle-specific-tuned with ICON-engineered Eibach springs, CAD-plated body, 7/8" shaft FK rod end bearings
• 2.0 Aluminum Series Monotube Rear Shocks: remote reservoir, 5/8" shaft, balances front performance for consistent all-terrain feel
• 1–3" Adjustable Lift: coilover height adjustable for leveling or tire-clearance needs on a stock-equipped vehicle
• 6061 Aircraft-Grade Aluminum CNC Components: corrosion-resistant construction throughout
• 100% Bolt-On Installation: no drilling, cutting, or welding required
• Fully Serviceable Shocks: front and rear shocks can be rebuilt (Application Note #55)

Specifications

Who This Is For and Isn't

This system suits 2011-and-newer Ford Ranger T6 4WD owners who want a 1–3" adjustable lift with improved on- and off-road ride quality, remote reservoir damping performance, and the ability to run up to 32×11.00" aftermarket tires without body modifications.

This system does not fit Ford Ranger T6 2WD variants or any other make and model. Tires larger than 32×11.00" will require fender trimming and additional modifications. This kit does not include wheels or tires.

Common Questions

What vehicles does this Stage 2 system fit?

The ICON Stage 2 Suspension System is designed specifically for 2011-and-newer Ford Ranger T6 4WD trucks. It does not fit the 2WD Ranger T6 or any other vehicle platform.

What components are included in the Stage 2 kit?

The Stage 2 kit includes one ICON 2.5" remote reservoir coilover kit for the front axle (part 91210) and two ICON 2.0 Aluminum Series remote reservoir rear shocks (part 96517R). Wheels and tires are not included.

Does installation require cutting, drilling, or welding?

The ICON Stage 2 system for the Ford Ranger T6 4WD is a 100% bolt-on kit. No drilling, cutting, or welding is required for installation. An installation guide is available from ICON Vehicle Dynamics.

What tire and wheel sizes are recommended with this lift?

ICON recommends 17×8.5 aftermarket wheels with 5" backspace and 32×11.00" tires with this Stage 2 system. OEM wheels and tires also fit. Tires larger than 32×11.00" may fit but will require fender trimming and modifications.

Can the shocks be rebuilt or serviced?

Yes. Both the front 2.5" coilovers and the rear 2.0 Aluminum Series shocks in this Stage 2 system are fully serviceable, per ICON Application Note #55.
