ICON Stage 1 Suspension System for 1991-97 Toyota Land Cruiser 80 Series 3-Inch Lift

The ICON Stage 1 Suspension System for the 1991–97 Toyota Land Cruiser 80 Series delivers a 3-inch lift engineered to improve on-road handling while expanding off-road capability, using ICON 2.0 Aluminum Series IFP shocks, dual rate coil springs, and all hardware required for a fully bolt-on installation.

Shipping: ICON parts ship direct from ICON Vehicle Dynamics, mostly by UPS Ground. Lead times vary by part and some items are built to order, so please allow extra time. We email tracking as soon as your order ships.

More Travel, Front and Rear

The Stage 1 system increases front wheel travel by approximately 40% over stock and rear wheel travel by approximately 35% over stock. That additional suspension articulation translates directly to better wheel contact on uneven terrain, keeping the truck planted where a stock suspension would lose traction, without sacrificing the compliance needed for daily driving.

Shocks Built for This Truck

The 2.0 Aluminum Series shocks use an internal floating piston (IFP) design with a 5/8-inch shaft and a corrosion-resistant anodized 6061 aircraft-grade aluminum body. Valving is tuned specifically for the 80 Series, balancing damping front to rear rather than applying a generic tune. The result is controlled body motion on pavement and predictable damping behavior on trail.

Bolt-On Installation, No Fabrication

The Stage 1 kit includes dual rate coil springs, caster correction bushings, sway bar relocation hardware, a brake line kit, and all bracketry, and every piece installs without drilling, cutting, or welding. The 4.6-degree caster correction kit restores factory steering geometry at the lifted ride height. All shocks are fully serviceable after installation.

Features

• 3-inch lift height: engineered around a typical loaded 80 Series build with heavier front bumper, winch, and rear bumper
• ~40% more front wheel travel / ~35% more rear wheel travel over stock
• ICON 2.0 Aluminum Series IFP shocks: vehicle-specific valving, 5/8-inch shaft, anodized 6061 aluminum body, front and rear
• Dual rate coil springs: ICON-engineered front and rear kits for on-road compliance and off-road performance
• 4.6-degree caster correction kit: restores steering geometry at lift height
• 100% bolt-on: no drilling, cutting, or welding required

Specifications

Who This Is For and Isn't

This system suits 1991–97 Toyota Land Cruiser 80 Series owners who want a 3-inch lift with meaningfully more wheel travel for off-road use while retaining a composed on-road ride. The bolt-on design makes it accessible to builders who want a complete, engineered kit rather than sourcing components individually.

The included brake line kit (part 53009) fits 1993–97 Land Cruisers only, not 1991–92 models. Owners of 1991–92 trucks should confirm brake line compatibility before ordering. This system is not a universal fit and is not designed for any other Toyota model or generation. Tires larger than 33x11.50 inches may require fender trimming or additional modifications.

Common Questions

Which model years does this suspension system fit?

The ICON Stage 1 system is designed for the 1991–97 Toyota Land Cruiser 80 Series. Note that the included brake line kit fits 1993–97 models only; owners of 1991–92 trucks should verify brake line compatibility separately before purchasing.

Does installation require cutting, drilling, or welding?

No. The Stage 1 system is a 100% bolt-on kit. All bracketry and hardware required for installation are included, and no drilling, cutting, or welding is necessary to complete the install.

What shocks are included, and are they serviceable?

The kit includes two ICON 2.0 Aluminum Series IFP front shocks and two ICON 2.0 Aluminum Series IFP rear shocks, all with vehicle-specific valving and a 5/8-inch shaft. The shocks are fully serviceable after installation.

Will the lift height be exactly 3 inches on my truck?

ICON's advertised 3-inch lift height is based on a typical loaded 80 Series build that includes added weight from a heavier front bumper, winch, and rear bumper. On a stock-weight vehicle, actual lift height may be higher than 3 inches.

Does this system work with stock wheels and tires?

Yes, the Stage 1 system is confirmed compatible with OEM wheels and tires. For aftermarket fitment, ICON recommends 17x8.5-inch wheels with 4.63-inch backspace and 33x11.50-inch tires; tires larger than that may require fender trimming or other modifications.
