DV8 Offroad Tube Front Bumper for GMC Canyon 2023–2026

The DV8 Offroad Tube Front Bumper (FBGC3-02) is a high-clearance, bolt-on steel front bumper built for the 2023–2026 GMC Canyon across all trims. The high-profile design is engineered to handle both desert-speed running and technical rock crawling, with an integrated full skid plate and a built-in solid steel recovery point. The bumper ships with a push bar and is finished in micro-texture black powder coat with gray accent skid plates.

Built to Clear Rocks and Keep Moving

The ultra-high-clearance profile of this Canyon front bumper reduces the risk of the front end catching on rocks during technical trail sections. The integrated full skid plate adds a layer of protection beneath the bumper, deflecting rock strikes and trail debris that would otherwise reach the frame or front-end components. Gray accent skid plates reinforce the underside and give the bumper a prerunner-style appearance. Together, the clearance geometry and skid plate coverage mean the truck can push through terrain without the driver managing a vulnerable front end.

A Light Bar or Eight Pods, Your Choice

The center section of this bumper accepts a 20-inch dual-row light bar or up to six 3-inch pod lights, and each side wing adds a mount for one additional 3-inch pod. The included push bar extends the lighting platform further: it supports a single 20-inch light bar, four 7-inch round lights, or up to eight 3-inch pods. Welded zip-tie tabs are built into the bumper structure so wiring can be routed cleanly without aftermarket brackets or adhesive clips. Lights are not included and are sold separately.

Recovery Point Retained Where Tube Bumpers Often Lose It

Many tube-style bumpers trade the front recovery point for clearance. This bumper keeps a solid steel recovery point integrated into the structure, so a front pull remains available without adding a separate receiver or shackle plate. The bumper does not obstruct the factory front camera and does not interfere with factory sensors, so driver-assist features remain functional after installation.

Features

• High-clearance high-profile design: suited for desert running and technical rock crawling
• Integrated full skid plate: with gray accent skid plates for front-end protection
• Flexible light mounts: center section fits a 20-inch dual-row bar or up to six 3-inch pods; each side wing mounts one 3-inch pod
• Included push bar: adds mounts for a 20-inch bar, four 7-inch round lights, or up to eight 3-inch pods
• Built-in solid steel recovery point: retains front pull capability
• Welded zip-tie tabs: for clean, integrated wire routing

Specifications

Who This Is For and Isn't

This bumper suits 2023–2026 GMC Canyon owners who run technical trails or desert terrain and want a high-clearance front end with integrated skid protection, a retained recovery point, and a flexible lighting platform. It is compatible with all Canyon trims in that model year range.

This bumper does not fit any vehicle outside the 2023–2026 GMC Canyon. It does not retain the factory skid plate or factory fog lights. The DV8 Tube Series (FBGC3-02) and the DV8 Spec Series (FBGC3-01) each require unique cut lines that do not overlap, making them incompatible as direct replacements. Professional installation is recommended given the cutting required.

Common Questions

Does this bumper fit every GMC Canyon trim from 2023 through 2026?

The DV8 Tube Front Bumper (FBGC3-02) fits all trims of the 2023–2026 GMC Canyon. It does not fit the Chevy Colorado or any other model year of the Canyon outside that range, even where the platform is shared.

Are lights included with this bumper?

No lights are included. The DV8 Tube Front Bumper provides mounts only: a center section for a 20-inch dual-row light bar or up to six 3-inch pods, side wings for one 3-inch pod each, and a push bar that supports a 20-inch bar, four 7-inch round lights, or up to eight 3-inch pods. All lighting is sold separately.

What cutting does installation require, and how long does it take?

Installing this Canyon front bumper requires cutting the factory bumper, fascia, inner grille, and wheel well liner. The installation is otherwise bolt-on. DV8 Offroad estimates approximately 6.5 hours for the job; actual time will vary with experience and shop setup.

Will this bumper block the factory front camera or affect driver-assist sensors?

The DV8 Tube Front Bumper is designed so it will not obstruct the factory front camera and will not interfere with factory sensors. Factory fog lights are not retained, but camera and sensor functionality carries over.

Can I install this bumper if my Canyon already has the DV8 Spec Series bumper?

No. The DV8 Tube Series (FBGC3-02) and the DV8 Spec Series (FBGC3-01) each require unique cut lines in the factory fascia and body panels, and those cut lines do not overlap. A Canyon that has been cut for the Spec Series cannot accept the Tube Series as a direct replacement.
