BulletProof Hitches Medium Duty Sway Control Dual Ball Mount

The BulletProof Hitches Medium Duty Sway Control Dual Ball Mount is a solid-steel dual-ball mount that provides the hitch-side attachment point required to run a sway control system on heavy trailer loads. It fits all steel Medium Duty BulletProof Hitches and is rated for up to 14,000 lb of trailer weight and 2,000 lb of tongue weight. The sway control system itself is sold separately.

Built to Handle Heavy Loads

The ball mount is machined from solid steel and finished in the same black textured powder coat as the BulletProof Hitch, so it matches the receiver and resists corrosion over years of use. On the 2-5/16" ball, the trailer weight rating reaches 14,000 lb, matching the upper capacity of the Medium Duty BulletProof Hitch line and giving tow-vehicle owners a sway control foundation rated to the same capacity as the hitch itself.

Two Balls, Two Mounting Sides

The mount carries both a 2" ball (rated 10,000 lb trailer / 2,000 lb tongue) and a 2-5/16" ball (rated 14,000 lb trailer / 2,000 lb tongue), so one piece covers the two most common trailer coupler sizes without swapping hardware. The 3/4" mounting plates on both sides of the ball mount let the sway control bar attach to either the driver or passenger side of the trailer, or allow two sway control systems to be run simultaneously on especially large or wide loads.

Ready to Install

The mount ships with the 1-1/4" ball needed to connect the sway control bar, plus two corrosion-resistant pins and R-clips that lock the ball mount into the channel of the hitch. No additional hardware is required to mount this piece to a compatible BulletProof Hitch.

Features

• Dual-ball configuration: 2" and 2-5/16" balls on a single mount
• 14,000 lb trailer weight rating: on the 2-5/16" ball; 10,000 lb on the 2" ball
• 2,000 lb tongue weight rating: shared across both balls
• 3/4" mounting plates on both sides: supports single or dual sway control system setups
• Solid steel construction: black textured powder coat finish
• Hardware included: 1-1/4" sway control ball, two corrosion-resistant pins, and R-clips

Specifications

Who This Is For and Isn't

This ball mount suits owners of steel Medium Duty BulletProof Hitches who need a hitch-side mounting point for a sway control system when towing large or heavy trailers, particularly those using 2" or 2-5/16" couplers up to 14,000 lb trailer weight.

This mount does not fit Light Duty or Heavy Duty BulletProof Hitches, and it is not compatible with non-BulletProof hitch receivers. The sway control bar and system are sold separately and are not included with this mount.

Common Questions

Does this ball mount include the sway control system?

No. The BulletProof Medium Duty Sway Control Dual Ball Mount provides the hitch-side attachment point only: the dual ball mount, the 1-1/4" sway control ball, two corrosion-resistant pins, and R-clips. The sway control bar and system must be purchased separately.

Which BulletProof Hitches does this ball mount fit?

The BulletProof Medium Duty Sway Control Dual Ball Mount is compatible with all steel Medium Duty BulletProof Hitches. It is not designed for Light Duty or Heavy Duty BulletProof Hitch models.

Can I run two sway control systems at once with this mount?

Yes. The 3/4" mounting plates on both sides of the BulletProof Medium Duty Sway Control Dual Ball Mount allow a sway control bar to be attached to either side of the trailer, or two separate sway control systems to be run simultaneously for especially large loads.

What trailer coupler sizes does this ball mount support?

The BulletProof Medium Duty Sway Control Dual Ball Mount includes both a 2" ball, rated for trailers up to 10,000 lb, and a 2-5/16" ball, rated for trailers up to 14,000 lb. Both balls share a 2,000 lb tongue weight rating.
